Burning the Bones of the Earth

Explore the now-ruined estates of the Irish countryside and you occasionally find a stone cylinder, as much as several metres high and wide, open at the top and with a small door at the base.

Some resemble the medieval fortresses that still dot the landscape here – but no one built fortresses so tiny, or half-buried in the side of a hill. In fact, they are kilns for lime burning, a now-forgotten industry that sustained many agrarian communities before energy became cheap.

“Lime” here means neither the citrus fruit nor the tree, but refers to a white powder derived from limestone. For at least 7,000 years humans created lime in kilns, as they might have hardened pottery or smelted ore, and used the material for dozens of purposes now largely replaced by fossil-fuel by-products – perhaps most commonly to create mortar for construction.

British and Irish farmers, though, found it most important to neutralise acid soils and multiply crop production – as much as fourfold, by some contemporary accounts. For hundreds of years until the mid-20th century, lime supported a vast and vital network of village industry —
quarries to mine the limestone, carts and barges to transport it, and specialists to monitor the burning. In the late 1700s, according to one survey, County Cork alone was said to contain an amazing 23,000 kilns, or one every 80 acres. ¹

Limestone is mainly coral and shells of long-extinct sea creatures, squeezed over aeons into a solid mass of calcium carbonate, or CaCO3. When burned at 900 degrees C or more it vents carbon dioxide (CO2), leaving behind the volatile calcium oxide (CaO) – “quicklime” or “unslaked lime.”

Then, when combined with water – hydrated or “slaked” — the quicklime became calcium hydroxide or Ca(OH)2, and could be put to many uses. Confusingly, all of these have been called “lime” at times, but in this article, we will call the original rock “limestone,” the caustic material from the kiln “quicklime,” and the hydrated final product “lime” for clarity.

Roman Concrete

The earliest use of lime dates to present-day Turkey between 7,000 and 14,000 years ago, and many ancient civilisations used it to create mortar between stones. The Romans, however, took lime a step further, mixing it with various other ingredients to create an early version of cement. In fact, their version has proven superior to our own in some ways. Our concrete lasts only decades – as little as a single decade in seawater — while Romans created concrete that not only formed in seawater, but have withstood the pounding of waves for 2,000 years. ^{2 3}

The secret, according to two papers released in the summer of 2013, involved mixing quicklime with volcanic ash to form mortar. Volcanic ash was plentifully gathered from the volcano at Vesuvius, according to Pliny the Elder – ironically, the same volcano that would later kill him. Romans then packed this mortar into wooden forms and lowered them into seawater, which caused the quicklime to react and form a lime-and-ash mix of waterproof cement. ^{4 5}

The papers’ authors say such techniques could prove useful even today; not only did their concretes stand up to time and the elements better than ours, but such methods are “greener” – generating less carbon emission – than our cement manufacture. Crushing rocks into Portland cement powder requires enormous quantities of energy and accounts for seven per cent of all industrial carbon emissions on the planet. ⁶

Romans brought such technologies with them as they spread across Europe, so lime kilns appeared in Britain with their invasion and disappeared for several hundred years after they left. In Ireland, where Romans never set foot, Normans apparently brought the technology in the 1200s, to build the round towers that still frequently stand today.

Whitewash, Limelight and other Applications

Lime also forms the basis of whitewash, used for centuries to protect and brighten structures, fences, vehicles and even trees, without the alarming and unpronounceable stew of toxic ingredients in many modern paints. Whitewash is fundamentally a mix of lime and water, although it could also contain salt, milk, linseed oil for water-proofing, or hair or cereal husks for strength.

The dried lime was safe to handle and even for animals to lick, but remained mildly alkaline enough to disinfect barn and dairy walls. Its brilliant whiteness was valued in places like Britain and Ireland, where the winters grow very dark – Irish cottages were traditionally whitewashed in spring and again before Christmas. In sunnier climates, however, that same colour helped keep buildings cool.

Lime had many other uses: Farmers rubbed it on their livestock’s feet as an antiseptic, or painted it onto fruit trees to prevent fungal diseases. Some mixed a bit of lime into well-water to disinfect it, or to preserve eggs for months without spoiling. Tanners used it to remove hair from hides, gardeners to repel slugs and snails, printers to bleach paper.

Even the corrosive quicklime, the calcium oxide that came straight from the kiln, had many uses before it was hydrated. It kept pantries and store-rooms dry – the 1915 household manual “The Best Way” recommended keeping a bowl of it to reduce humidity, as it sucked moisture from the air. It caught fire easily – sometimes too easily – and was used to make an early, high-intensity lamp for the stage – the original limelight. ⁷

Terrorist Weapon

It also made a rather fearsome weapon, as it could sear the skin and blind the eyes. In David Hume’s A History of England, he recounts a battle between English and French ships around 1216, in which the English captain Phillip d’Albiney ingeniously used quicklime to turn the tide of battle. He saw that the winds were blowing from his ships to French fleet, and “having gained the wind of the French, he came down upon them with violence; and throwing in their faces a great quantity of quick lime, which he purposely carried on board, he so blinded them, that they were disabled from defending themselves.”

The compound made a handy terrorist weapon as well; when Irish reformer Charles Parnell spoke at a political rally in 1891, someone in the crowd threw quicklime at his face, and “had not [he] shut his eyes in time, he would undoubtedly have been blinded,” his wife Katherine later wrote.

Quicklime was also shovelled into graves to decompose bodies more quickly, as Oscar Wilde saw when he was a prisoner at Reading Gaol (Jail) in Britain:

And all the while the burning lime Eats flesh and bone away
It eats the brittle bone by night
And the soft flesh by the day
It eats the flesh and bone by turns
But eats the heart away.

Lime in Agriculture: Sweetening the Soil

Its use in agriculture, however, eclipsed any other use on these islands, so valuable was its ability to turn acid bog-lands into croplands. Some 40 per cent of the arable land in the world is too acidic for many plants to grow – the more acidic the soil, the more toxic aluminium plants absorb. These days, farmers often treat such soils with crushed limestone or other energy-intensive products, and scientists like Chris Gustafson of the University of Missouri are trying to genetically engineer aluminium-resistant crops. In earlier eras, however, farmers found that lime temporarily “sweetened” or neutralised the soil. ⁸

This made lime so valuable that many agrarian communities supported a network of local industries to create it — quarries to mine the limestone, wagons to transport the rocks by road or barges by canal, and specialists to supervise the burning. By the mid-1600s many families in County Cork, Ireland, for example, paid their rent by lime-burning on the side, according to a civil survey of the time. ⁹

Farmers treated the soil in quite a straightforward manner: they shovelled quicklime straight from the kiln onto a horse-drawn cart, drove the cart to the needed field and drove the horse back and forth across it as though ploughing. Every several metres the farmer stopped the cart and scooped several shovels of quicklime in “falls” on the ground — six to eight barrels to the acre.

Spreading a highly caustic compound onto cropland might sound inadvisable, but the next rain both hydrated it into lime and soaked it into the ground. Transporting the quicklime, however, was dangerous work, as it could spontaneously burst into flame and burn carts and barns, or simply to eat through wooden containers if it wasn’t spread quickly. ^{10 11}

The process only sweetened the land for a limited amount of time, according to contemporary reports – three years in some fields, twelve years in others, depending on conditions. In any case liming had to be continually re-applied or it “enriched the father but impoverished the son,” went the saying, so the kilns were kept in steady business. ¹²

Operating the Kiln

Kilns themselves needed to be carefully situated: they needed to be as close as possible to quarries, so that hundreds of tonnes of rock could be carried with as little effort as possible, by horse or barge. At the same time they had to lie as close to the lime’s destination as possible – a fortress or church being built with mortar, or fields that needed sweetening — so that the quicklime could also be transported without incident. Moreover, they could not be situated near populated areas or even campsites, as the burning lime gave off noxious and potentially lethal gases.

The brick or stone structures were often built into hillsides to allow people to easily transport coal and lime to the open top, or mouth, and were often several metres across and about as high. On the inside they usually tapered down so that gravity alone fed the fuel down, and at the narrow bottom of the cone, one wall had an arched opening or “eye.”

The kiln had to be filled carefully, with precisely measured amounts and materials – if the lime did not bake at a high enough temperature for long enough, the stone would not transform into quicklime and the work would be in vain. Lime-burners filled the bottom of the kiln with the driest wood possible – furze-wood was often mentioned – and then the men lay alternating layers of fuel and limestone.

Perhaps the most common fuel was “colm” – anthracite coal – although charcoal could also be used, as well as “turf” – dried peat from the bogs here. Whatever the fuel, it had to be in an opaque layer, insulating the chunks of limestone from the sides of the kiln and from each other, according to old lime-burners interviewed decades later for Irish national radio.

Sleeping by the Kiln

Once the kiln was filled, the wood – at the bottom of the kiln, by that little door – was set on fire, and that, in turn, lit the fuel through the rest of the structure. Once the kiln was lit there was no going back; the lime-burners had to maintain a watch over the kiln for the next three or four days, sleeping nearby.

Burning was often done in winter, when there were fewer farm chores to be done, so it must have been tempting for men sleeping out in the cold to move closer to the warm glow of the kiln. According to lime expert Colin Richards, however, sleeping by the kiln was extremely dangerous, between the poison gases and the open pit.

Certainly the men did exhausting work for days at a stretch, making them “thirsty as a lime-burner” as the saying went. A single kiln could hold a hundred tonnes of material, which had to be shovelled in by hand, yet delicately measured and arranged inside. Of course there was less to shovel out – the coal had burned away, and the limestone had lost some of its mass – but that material was much more difficult to handle.

“Drawing out the lime underneath was the dirtiest part of it,” said one anonymous lime-burner who worked in Ireland in the 1930s and 40s and was interviewed for a radio documentary in 1981. “It was there that you got the dust, and you got too much of it and you began bleeding from the nostrils.”

Magic and Ritual

With their furnace-like heat, poison vapours, alchemical transformations, hazardous products and vital importance to agrarian survival, it was perhaps inevitable that farmers associated kilns with all kinds of magic and ritual. According to Irish elders interviewed in the 1930s, young people often performed Halloween rituals to find out who they would marry.

In one instance, fairies were said to have killed off a farmer’s livestock after he inadvertently built a kiln in their way. Other peoples were said to have summoned evil spirits there; a reverend in Carnmoney, rumoured to have sold his soul to the Devil, was said to have courteously invited him to a kiln so the Devil would feel at home. ^{15 16 17}

The Irish lime burners themselves had a simpler ritual, one they said was practiced among “all the lime burners of old.”

“You took a bottle with you that morning … of holy water,” one said, and before the kiln was fired up “you just sprinkled it on top the stones, and made the Sign of the Cross, for you were burning ... the bones of the Earth.”



Originally published in Low-Tech Magazine.

Top photo: Kiln in Poland. Photo by Jacek Halicki

Middle photo: Whitewashed house near us.

Bottom photo: My limewater eggs, which stayed edible for several months.

1. A Topographical Dictionary of Ireland by Samuel Lewis, 1837.
2. “Microscopy of historic mortars — a review,” by J. Elsen, Cement and Concrete Research, July 2005
3. “Chemistry and Technology of Lime and Limestone,” J. Elsen, Cement and Concrete Research, December 2005
4. “Material and elastic properties of Al-tobermorite in ancient Roman seawater concrete,” by Marie D. Jackson, Juhyuk Moon, Emanuele Gotti, Rae Taylor, Abdul-Hamid Emwas, Cagla Meral, Peter Guttmann, Pierre Levitz, Hans-Rudolf Wenk, and Paulo J. M. Monteiro, Journal of the American Ceramic Society.
5. “Unlocking the secrets of Al-tobermorite in Roman seawater concrete,” by Marie D. Jackson, Sejung Rosie Chae, Sean R. Mulcahy, Cagla Meral, Rae Taylor, Penghui Li, Abdul-Hamid Emwas, Juhyuk Moon, Seyoon Yoon, Gabriele Vola, Hans-Rudolf Wenk, and Paulo J. M. Monteiro, American Mineralogist.
6. “Roman Seawater Concrete Holds the Secret to Cutting Carbon Emissions,” Berkeley, http://newscenter.lbl.gov/news-releases/2013/06/04/roman-concrete/
7. The Best Way - A Book Of Household Hints & Recipes, 1915
8. “Famine Fighter,” Illumination magazine, Spring / Summer 2013
9. The Ancient and Present State of the County and City of Cork, by C. Smith, 1815 edition.
10. “Burning the Bones of the Earth,” a documentary by Radio Telefis Eireann, 1981
11. Edwardian Farm, BBC Television
12. Essay on the Use of Lime as a Manure, by M. Puvis, 1836.



The magic of hot composting

Ordinary composting has some disadvantages that every gardener knows well. One can’t simply add bones or meat – and some gardeners even avoid eggshells – for fear of attracting vermin. Also, plants that have gone to seed cannot be added, or the resulting soil will be peppered with the beginning of next year’s weeds. You can’t add diseased plants, or the diseases might remain in the resulting soil, ready to infect next year’s crops. Also, it takes a long time, and one loses much of the kitchen waste volume in the process of rotting down.

Imagine, then, a new kind of composting, one that avoids all these problems at once – no more weed seeds, no more disease, no more vermin. Imagine being able to compost almost everything, and keep the majority of the biomass. Imagine, finally, that it only takes a matter of weeks and not months.

What makes hot composting, or Berkeley composting, work is the kind of bacteria it uses. Instead of the usual variety of bacteria that breaks down over several months, hot composters find the right balance of materials – more on this in a moment -- to attract aerobic, heat-generating bacteria. The bacteria generate heat just as your body does, enough to kill any weed seeds and diseases.

To do this yourself, you need the right balance of materials to compost; if the carbon/nitrogen ratio is too high in carbon, the compost will not get hot enough or break down quickly enough, and one must add something like manure or grass clippings. If the mix has too much nitrogen, rather smelly bacteria will take over, and the mix might get slimy.

The desired ratio sits between 25 and 30 parts carbon-rich waste to one part nitrogen-rich waste, proportioned by weight. Carbon-rich materials are typically dry and brown, like sawdust, cardboard, paper, dried leaves, straw and other, similar things. Nitrogen-rich materials are typically moist and fresh, like kitchen waste, fresh lawn clippings and vegetable scraps. Sometimes carbon-rich materials are called “browns” and nitrogen-rich materials “greens” for simplicity, but these terms can be misleading: coffee grounds and animal manure, whatever their colour, would also be nitrogen-rich.

To get the right C/N ratio, keep in mind that all plants have more carbon than nitrogen, so virtually all materials have a ratio of at least 1/1. Wood chips have a ratio of 400/1, newspaper has 175/1, and straw has 75/1. Vegetable scraps are about 25/1, fresh grass clippings 20/1, and chicken manure  about 12/1. Urine has a ratio of about 1/1, and is excellent to add to soil in whatever way does not violate your social anxieties or local ordinances.

It is a bit awkward at first to weigh things before adding them and then do the math, but you quickly get a feel for the practical effects of your most common additions and see how they affect the whole, in the same way that you do with cooking. You can adjust the ratio of certain additions; for example, by letting some of your lawn clippings dry and then raking them up, while mowing another section into a bag and depositing while still green, to get the ratios you want.

To start experimenting with this, first fill a cubic area about 1.5 metres across each way with kitchen waste. Leave the compost for four days with no turning; unlike regular casual composting, do not keep adding new material to the same bin once you’ve started. It would also be best to get a long thermometer to see how hot it’s getting; don’t let the temperature drop below 55 C (130 F); if that happens, adjust the ratio or turn it to oxygenate it. Nor should you let the temperature rise above 70 C (160 F); if that happens, air the pile out some or run a water hose through it – as I discuss below -- to extract some of the heat.

Then, turn the compost every second day for the next 14 days to oxygenate it, making sure to turn it thoroughly from the outside in to get everything well mixed. By the 18^th day, it should look like soil – but you still need to let it rest for several more weeks before planting in it.

Not everyone has the amount of organic waste to try this, but you could get your neighbours to participate by getting them to contribute and reduce their trash bill, or do the same for local shops that have produce they throw away. If you live near a park, you could see if the city wants somewhere to put their lawn clippings.

Composting this way generates heat that some people can use to heat their homes or water supply – I’ve taken a very hot shower outside on a very cold Irish morning, using no electricity or fossil fuels. I just snaked the hose up through the compost, and the heat from the bacteria heated the water by itself. In theory, houses in northerly climates could build adjacent hot compost bins, perhaps in conjunction with an attached greenhouse, and could run their water pipes through it.

Such simple innovations, if handled rightly by the households, would turn their waste into soil quickly at a time when we are rapidly losing soil to erosion. It would cut their emissions from garbage and at the same time cut their emissions from fossil fuels, since they would not have to burn as much gas or oil. It would reduce their debt, and their dependence on government and corporations, all at the same time. Few simple, at-home innovations could have a wider impact if widely embraced.

Photo courtesy of Wikicommons.
